Packard Bell Executive MM 923 D
Motherboard RH-TKTHPackard Bell at its mid-nineties height, when it was the biggest name in retail PC sales and almost unknown to anybody who bought direct: a Pentium on an LPX board with the graphics, the sound and the CD-ROM already fitted, so the carton held the whole computer. Assembled in France for the European market. Ordinary then and uncommon now — they were bought to be used up, and nobody thought to keep one.
Details
| Manufacturer | Packard Bell |
|---|---|
| Model | Executive MM 923 D |
| Year | 1996 |
| Serial | PSPK62206749 |
| Condition | Working |
| Source | TME Matt |
| Acquired | 2026-09-05 |
| Installed in | RH-9239 |
| Reference | https://theretroweb.com/motherboards/s/intel-pl430fx-advanced-pl-thousand-oaks |
Machine
| Catalogue model | Executive MM 923 D — Packard Bell, 1996 |
|---|
Chips fitted — what is marked on each
Cirrus Logic CL-GD5440
Specs
| Chipset | Intel 430FX |
|---|---|
| CPU family | Pentium-class |
| Form factor | proprietary |
| RAM slots | 4× 72-pin SIMM |
| Slots | 3× 16-bit ISA, 2× PCI |
| BIOS | AMI 1.00.07.CP0R |
| Onboard video | VGA CL-GD5440 |
| Ports | 2× IDE, Floppy, Serial, Parallel, PS/2 keyboard, PS/2 mouse |
| Cache | COAST |
Files
No files for this one yet.
History
| 2026-09-06 |
fetched a photo from the reference
|
| 2026-09-06 |
year: (empty) → 1996
serial: (empty) → PSPK62206749
condition: (empty) → Working
source: (empty) → TME Matt
acquired_date: (empty) → 2026-09-05
url: (empty) → https://theretroweb.com/motherboards/s/intel-pl430fx-advanced-pl-thousand-oaks
Chipset: (empty) → Intel 430FX
CPU family: (empty) → Pentium-class
Form factor: (empty) → proprietary
RAM slots: (empty) → 4× 72-pin SIMM
Slots: (empty) → 3× 16-bit ISA, 2× PCI
BIOS: (empty) → AMI 1.00.07.CP0R
Onboard video: (empty) → VGA CL-GD5440
Ports: (empty) → 2× IDE, Floppy, Serial, Parallel, PS/2 keyboard, PS/2 mouse
Cache: (empty) → COAST
|
| 2026-09-06 |
detached from computer RH-9239
|
Photographs
1
