IBM 5170
Motherboard RH-UJDXDetails
| Manufacturer | IBM |
|---|---|
| Model | 5170 |
| Year | 1985 |
| Condition | Working |
| Source | Pete Short Circuit |
| Installed in | RH-0CDY |
| Reference | https://theretroweb.com/motherboards/s/ibm-at-type-5170-type-2 |
| Notes | Picked up faulty from Pete Short Circuit. It had bad traces under RAM, no crystal and no CPU, and was repaired, restoring full functionality. |
Specs
| Chipset | discrete |
|---|---|
| CPU family | 286-class |
| BIOS | IBM AT (1985 variant) |
| Ports | DIN keyboard |
Files
No files for this one yet.
History
| 2026-08-01 |
Chipset: discreet → discrete
|
| 2026-07-29 |
acquired_date: 2025 → (empty) — no month or day recorded
|
| 2026-07-29 |
notes: Picked up faulty from Pete Short Circuit. Bad traces under RAM, no crystal and … → Picked up faulty from Pete Short Circuit. It had bad traces under RAM, no cryst…
|
| 2026-07-27 |
added 1 photo(s)
|
| 2026-07-27 |
created
|
Photographs
1
